150 mm/min Strip Casting Machine 3000Mt Yearly Capacity Take Up Form Coiling

150 mm/min Strip Casting Machine 3000Mt Yearly Capacity Take Up Form Coiling
150 mm/min Strip Casting Machine 3000Mt Yearly Capacity Take Up Form Coiling

Large Image :  150 mm/min Strip Casting Machine 3000Mt Yearly Capacity Take Up Form Coiling

Product Details:
Place of Origin: China
Brand Name: E&V
Model Number: SYJ06250*10-I3
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: standrad packing
Delivery Time: 60 DAYS
Supply Ability: 1SET PER MONTH
Detailed Product Description
Color: Optional Yearly Capacity: 3000mt
Function: Producing Copper Strip Product: Copper Strip
Working Hour: 7920h Strand NO.: 6
High Light:

continuous casting equipment

,

continue casting machine

,

150 mm/min Strip Casting Machine

150 mm/min Strip Casting Machine 3000Mt Yearly Capacity Take Up Form Coiling







Main Technology Parameter Of Copper Strip Up-casting Machine



No. Item Parameter Remark
1 Model TPSYJ250*10*6-I3 Adjustable as per customer’s requirements
2 Yearly capacity 3000mt
3 Total power 250KW
4 Furnace structure three- body furnace(2melting furnace,1 holding furnace) Adjustable as per customer’s requirements
5 Casting strands 6 Adjustable as per customer’s requirements
6 Copper strip size 250*10mm Adjustable as per customer’s requirements
7 Casting speed 0-150mm/min
8 annual working time 7920h
9 Liquid tracking precision ±2mm
10 Take-up coil standard 600kg/coil
11 Copper melting velocity 380kg/h Adjustable as per customer’s requirements
12 Copper melting power consumption ‹350kwh/ton
13 Take-up form Coiling
14 Feeding mode whole piece of electrolytic copper cathode fed by electric hoist
15 Driven mode 3pc copper strip:1pc 4.4kwservo motor
16 Rod clamping method Manual clamping
