Four Axis Horizontal Copper Fine Wire Drawing Machine With Flip Up Security Door

Four Axis Horizontal Copper Fine Wire Drawing Machine With Flip Up Security Door
Four Axis Horizontal Copper Fine Wire Drawing Machine With Flip Up Security Door

Large Image :  Four Axis Horizontal Copper Fine Wire Drawing Machine With Flip Up Security Door

Product Details:
Place of Origin: China
Brand Name: E&V
Model Number: 17MDST
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: standard export packing
Delivery Time: 35 days
Supply Ability: 1set per 35days
Detailed Product Description
Name: Medium Drawing Machine Color: Option
Input Size: 2.6/3.0mm Output Size: 0.4mm
High Light:

steel wire drawing machine

,

continuous wire drawing machine



Four Axis Horizontal Copper Fine Wire Drawing Machine With Flip Up Security Door



Main technical parameters

  •  type:four-axis horizontal
  •  inlet wire scope:Ф3.2-Ф2.0mm
  •  outlet wire scope:Ф0.4-Ф1.2mm
  •  highest machinery machine speed:1200m/min(with anneal highest 1000 m/min)
  •  outlet speed:(for reference)
Outlet dia(mm) 1.20-0.80 0.80-0.60 0.60-0.40
Outlet speed(m/min) 17MDS 600--300 800--600 1200--800
Outlet speed(m/min) 17MDST 600--300 800--600 1200--600
elongation of cord 25-33% 20-28% 22-25%



  •  max eye mould:17
  •  eye mould size:Ф30mm×15mmT or Ф25mm×10mmT

8. extend wire reduce rate:1-16 eye moulds: 15%

17 eye mould: 11%

9  extend wire lubricating system:spray type

10 quantity demaned of extend wire oil:100lit/min

11, drawing oil : 100 liter/minute

12, drawing machine use horsepower:45KW-4P

13, coiler use horsepower:11kw-4P induction motor

14, cable:90W motor cable,attach limit switch

15, security door:flip-up



any questions for this machine, plz let contact us!!!
