Multifunctional 2 Roller Cold Metal Rolling Mill For 20mm - 8mm Metal Wire

Multifunctional 2 Roller Cold Metal Rolling Mill For 20mm - 8mm Metal Wire
Multifunctional 2 Roller Cold Metal Rolling Mill For 20mm - 8mm Metal Wire

Large Image :  Multifunctional 2 Roller Cold Metal Rolling Mill For 20mm - 8mm Metal Wire

Product Details:
Place of Origin: China
Brand Name: EV
Model Number: JC-RM248(Ф20-Ф8)-10P-2C
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: standrad export packing
Delivery Time: 120days
Supply Ability: 1set per month
Detailed Product Description
Material: Copper Or Copper Alloy Color: Optional
Rolling Size: 20mm-8mm Delivery Time: 120days
Power: 180kw Size For Machine: 12000*6000*2300mm
Capacity: 2.5ton/hour Speed: 1.6m/s
Weight: 20ton
High Light:

rod rolling machine

,

2 high rolling mill

Multifunctional 2 Roller Cold Metal Rolling Mill For 20mm - 8mm Metal Wire



Feature



1. The machine is for rolling. The rod after rolling can greatly improve mechanical property and remedy defect from casting. This speed can reach to 5m/s for this series.



2. The most important thing of mental process craft is forming system technology. It plays a more and more remarkable role in modern manufacture process, at the present, the rolling machine usually use big motor or huge and bulky multistage mechanical transmission mechanism. The mechanism depends on fixed gear and belt for transmission and limit the speed of rolling for process unit and transmission mechanism. This system can only make single material. For example, copper rod mill can not roll aluminum rod. Different section need special machine to make, present system can not process special ally machine and so on, meanwhile,big transmission cases drive some frames to work but excessive current will waste more resources. Transmission system in cases will happen to abrasion when it has ling time to work, in the process, it may have some problems for instability, push and pull to influence product quality. Besides, process device and mechanism are setting not reasonably. It may take a lot of time and increase worker’s diffculties to change the roller. We need to reform and innovate available equipment because it will not meet modem enterprise’s requirements, from the market survey and demand, we haven’t have this practical application.in order to meet the demand of market, we must develop a mental machine system with multifunctional and small cross section.



3. The machine designed by us is each stand driven by separate frequency motor or servo motor, so each stand still is sync after changing the rolling pass of and rotation speed. Process roller can change the pass, and each rotation speed can be set on touch screen.thus, under the premise of meeting stand’s strength,two-roller cold rolling mill can roll different size of copper rod. Different material also. Like 17mm-8mm,or 14.4-8mm,or 12.5-6.8mm or 8-4mm. Its same like Germany’s.



Main Parameter



No. item Parameter
1 Model: Copper rod cold rolling mill, copper alloy cold rolling mill. Other metal rod cold rolling mill, other alloy cold rolling mill,copper / aluminum continuous casting and rolling etc.
2 Input dia Ф55mm,Ф35mm,Ф25mm,Ф20mm,Ф17mm,Ф16mm,Ф14.4mm,Ф12.5mm,Ф8mm etc.
3 Output dia Ф20mm,Ф18mm,Ф17mm,Ф8mm,Ф6mm,Ф5mm,Ф4mm,Ф3 mm etc.
4 Outlet rod out of roundness No more than 0.2mm after rolling, or more accurate
5 Rolling pass 2-16 or as each customer’s requirements
6 Rolling speed Max 3M/s for continuous rolling, Max 5M/s for discontinuous rolling.
7 Pass schedule ellipse-round hole type system or triangular -round type system
8 total extend compression ratio 2-10, or as each customer’s requirements
9 each pass compression ratio 1.15~1.4(hole type can change)
10 Total power 100kw~500kw
11 Running mode Each frame separate transmission speed controlled by frequency or AC servo
12 Operation mode PLC control, touch screen display,can improve to DCS control or networking
13 type 2 high horizontal- vertical or 3 high positive triangle-inverted triangle
14 nominal roller dia Ф200mm(double-groove/multi-groove),Ф248mm(double-groove/multi-groove),Ф264mm,Ф300mm,Ф370mm,Ф400mm etc.
15 No. of frame 2-16 or more
16 Main motor 11kw-110kw AC frequency motor or AV servo motor for each
17 roller material other imported material etc.
18 rolling mill size

a complete production line: length 18m *width 6 m*height 2.5m

Main machine : length 7.6m*width 2.3m *height 2m

19 height of center height from the ground 1230mm





some questions maybe you are interested in



1.What’s the system about Two-high mill and 3 roll mill?



Two-high mill pass system for: ellipse-round hole type system ; Three roll mill pass system : triangle -round system



2.The roundness of outlet rod is very big by the rolling mill,is it right?


NO, no more than 2mm.



3. Is it very difficult to operate the rolling machine ?


No.just need one person and the machine is very easy to be operated.


4 .what’s the main different between rolling mill and extrusion machine?


Rolling mill belong to cold process,extrusion machine belong to hot process.
