8mm 12000T Copper Rod Continuous Upcasting Machine

Good services and efficient works,I'd like to cooperation with them, it's my best eyes in china.

—— Raymond

Your goods are prefect in quality compared with those of other manufacturers.

—— Mr. Anil

I'm Online Chat Now

8mm 12000T Copper Rod Continuous Upcasting Machine

8mm  12000T Copper Rod Continuous Upcasting Machine
8mm  12000T Copper Rod Continuous Upcasting Machine 8mm  12000T Copper Rod Continuous Upcasting Machine

Large Image :  8mm 12000T Copper Rod Continuous Upcasting Machine

Product Details:
Place of Origin: CHINA
Brand Name: E&V
Model Number: SYJ1008-I3
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: standard packing
Delivery Time: 60days
Supply Ability: 1set per month
Detailed Product Description
Machine: Continuous Casting Machine Function: Making Rod
Strand Dia: 8mm Color: Optional
Output Each Year: 12000t Casting Speed: 0-3000
High Light:

8mm Copper Rod Continuous Casting Machine

,

12000T Upward Casting Machine

,

5 Body Furnace Upward Casting Machine

8mm 12000T Copper Rod Continuous Upcasting Machine



I, Introduction



The upcasting line (unit for shot as here below) is used to produce the long and bright oxygen-free copper rod. The induction melting furnace melt the copper cathode into liquid, the liquid keeps off the air by charcoal or graphite flake in case of be oxidation. The holding furnace keeps the copper liquid temperature in 1150℃±10℃, the casting machine crystallizes the copper liquid in crystallizer quickly, then continuously produces copper rod, then the final product will be finished through the double head take up machine and other accessory equipment.

II, Main data



No. Item Data
1 Model No SYJ2408-25-I5
2 Annual capacity 12000tons
3 Furnace structure 5body (3melting,2holding )
4 Casting Strands 24
6 Casting rod diameter: Ф8mm-Ф25mm
7 Upward casting speed 0~3000mm/min
8 Annual working time 7920hour
9 Liquid tracking precision ±2mm
10 Take-up coil standard Ф700mm × Ф1500mm× 800mm
11 Copper melting velocity 1520kg/h
12 Copper melting power consumption <350kwh/ton



III,Our advantages

1. The paperless recorder is used and is connected to the manager’s computer. All the temperature records within one month can be checked, through which the controlling of the furnace temperature can be more effective and the rod quality can be increased. (chose when the buyer need)



2. The gapless connecting expansion sleeve is used for the traction device, the PLC is used to control the servo motor correctly, and to assure that each order from the PLC is correct and accurate.



3. Energy-saving furnace is used for the upcasting line, which is having a larger power for single inductor, better melting effect, and a longer life. It has won the related patent: ZL 2010.2 0214505.5, ZL 2010.2 0214501.7, ZL 2006.2 0105926.8 ZL 2008.2 0162263.2.



IV,Some questions for this machine, maybe u are interested in

1.what’s the difference between up-casting machine and horizontal machine?



different way to casting machine,up-casting machine making oxygen-free copper rod ,but horizontal machine making low oxygen copper rod.the copper rod’s color is different



2.Do we need to making the furnace again if the water jack is broken?



No,just to change it.



3.How long the work hour about the up-casting machine?



7920h



4.What’s the speed about the up-casting machine?



0-3000mm/min
