Electrical motor wire and cable making machine 17mm 1000-12000 tons

Electrical motor wire and cable making machine 17mm 1000-12000 tons
Electrical motor wire and cable making machine 17mm 1000-12000 tons

Large Image :  Electrical motor wire and cable making machine 17mm 1000-12000 tons

Product Details:
Place of Origin: China
Brand Name: E&V
Model Number: SYJ1608-I3
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Packaging Details: standrad packing
Delivery Time: 60 DAYS
Supply Ability: 1SET PER MONTH
Detailed Product Description
Color: Optional Yearly Capacity: 1000-12000mt
Function: Producing Copper Rod Strand Qty: 2-24
Product: 8mm Copper Rod Working Hour: 7920H
Usage: Cast
High Light:

continuous casting machines


Vertical Casting Machine


wire and cable making machine 17mm

Electrical motor wire & cable making machine

(1)Main Introduction:

Upcasting Copper Rod Manufacturing Machine produced by professional designers through indepentent design and research and gained the reputation both at home and abroad.The induction melting furnace melt the copper cathode into liquid, the liquid keeps off the air by charcoal or graphite flake in case of be oxidation. The holding furnace keeps the copper liquid temperature in 1150℃±10℃, the casting machine crystallizes the copper liquid in crystallizer quickly, then continuously produces copper rod, then the final product will be finished through the double head take up machine and other accessory equipment.

NOTE: We can produce the up cast line according to your requirments

 (2)The technical parameter :

No. Item Data
1 Model No SYJ(02-24)**(08-35)-I2/3
2 Annual capacity 1000-12000tons
3 Furnace structure 3 body (2 melting,1 holding )
4 Casting Strands 2-24
6 Casting rod diameter: Ф8mm-Ф35mm
7 Upward casting speed 0~3000mm/min or 0-1500mm/min
8 Annual working time 7920hour
9 Liquid tracking precision ±2mm
10 Take-up coil standard Ф700mm × Ф1500mm× 800mm
11 Copper melting velocity 260-2525kg/h
12 Copper melting power consumption <350kwh/ton
13 Take-up form automatic adjust
14 Take-up plate driven approach inverter motor, PLC control
15 Material feeding method whole piece of electrolytic copper cathode fed by electric hoist
16 Upward driven approach driven by the AC servo motor, transmission chain is driven by the gapless synchronous cog blet
17 Rod clamping method air clamping or manual clamping




1) Removable inductor and easy to repair.

2) PLC controlling, and servo motor driven system.

3) Automatic collecting.

4) Quick lifting device is used for installing and changing the crystallizer.high-speed installing.

5)The controling system of furance temperature uses paperless recorder


(4)The reasons you choose us:

a.We have experienced team and high-tech equipments.

b.We use the computer program to control the whole product line, and we also use the servo motor to make sure the process automatic. So the manufacturing process is very safe and easily

c.Our equipments are using removable structure, many parts can be changed separately, so

it 's very easy for you to maintain plants.

d.We can offer you very competitive price.

e.You can get expert guides from us all the time.

f.we have perfect service,timely customer response



1. Delivery time: 60 working days after the complete receipt of the deposit.

2. The buyer bears the equipment transportation and insurance costs; the buyer provides

unloading tools and bears the unloading costs.

3. When the equipment arrives at the buyer's site, the buyer should check the goods, sign written receiving records, and confirm the consistency between the goods and the lists of shipment.
